The Double-Offset Butterfly Valves has a disc with two offsets and can be rated up to 1480 psi. Similar to a single-offset design, the stem is located behind the disc. With the high-performance butterfly valve, the second offset’s stem is moved once more off the center of the disc to one side. The double-offset butterfly valve is used in systems requiring higher pressure resistance.

SPECIFICATIONS

Size Range: 2” – 30”

Pressure Class: ASME 150 – 600

API Standard: 609

FEATURES

• Triple Eccentric Disc-Shaft

• Anti-Blow Out Stem

• Bi-Directional

• Firesafe Design

• Low Friction Body Seat

• Zero Leakage

• Wafer, Lug &  Flange Type

MATERIAL:

• Carbon Steel

• Stainless Steel

• Ductile Iron

• Other Materials upon Customer's Request
